To program the Level Star 3 for Example 3 Volume Application with
Control by using the Quick Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
Using the ‘right’ arrow key go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and ENTER.
Question
Option
Level/Volume
2= Volume App.
Control
1= Control Down
No. of Controls
1 = 1 Relay
Control No. 1
1 = Set Relay 1
No. of Alarms
2 = 2 Alarms
Type Alarm 1
1 = High
Alarm No. 1
2 = Set Relay 2
Type Alarm 2
2 = Low
Alarm No. 2
The unit knows that only Relay 3 is
available and so will automatically set
Alarm 2 to Relay 3.
Xducer (P101)
2 = dB6
Material (P102)
1= Liquid
Measnt Units (P104)
4 = feet
Empty Level (P105)
11.0 (feet)
Span (P106)
10 (feet)
Vessel Shape (P600)
0 = Cylindrical Flat Base
Vessel Dimensions
Enter Vessel Dimensions as requested
(depends on vessel shape chosen)
Volume Units
Select as required
Max. Volume (Read
Only)
Displays the Max Volume as calculated
by the Level Star
This example is for a cylindrical flat-bottomed vessel. See P600 Vessel
Shape in the following Parameter Guide, for a description of all the other
vessel shapes you could select. Some vessel shapes require additional
dimensions to be entered, and you will be asked for these during quick set-
up.
Programming is now complete and the unit can be returned to the run mode,
press CANCEL until Run Mode? Is displayed on the LCD press ENTER,
and the Level Star will return to the Run Mode.
