Pulsar Ultra 3 (UL) User Manual

Page 66
Wait ….
Parameter
Default
Description
P101 Transducer
2 = dB6
Type of transducer being used.
P104
Measurement
Units
4 = feet
Select units to be used for
programming measurement
information.
P105
Empty Level
19.685 feet
Distance from the face of the
transducer to the material at the
bottom of the vessel.
P106
Span
18.701 feet
Distance from the empty level (0%
full) to span (100% full).
For More Options Hit Enter
Parameter
Default
Description
P213 / P214
Relay 1
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Either Alarm or Pump control.
Depends on application.
P223 / P224
Relay 2
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P233 / P234
Relay 3
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P830
mA Out Range
2= 4 to 20 mA
Determines the mA output
range.
0 = Off, 1 = 0 to 20mA
2 = 4 to 20mA, 3 = 20 to
0mA, 4 = 20 to 4mA.
P870
Fill Damping
32.8084 feet/min
Rate of maximum fill rate (set
above the actual fill rate of the
vessel).
P871
Empty Damping
32.8084 feet/min
Rate of maximum empty rate
(set above the actual empty
rate of the vessel).
