Pulsar Ultra 3 (UL) User Manual

Page 91
For More Options Hit Enter
Parameter
Set Value
Description
P213 / P214
Relay 1
ON/OFF
setpoints
depends on
application
Set required Alarm Setpoints.
P223 / P224
Relay 2
ON/OFF
setpoints
depends on
application
Set required Alarm Setpoints.
P233 / P234
Relay 3
ON/OFF
setpoints
depends on
application
Set required Alarm Setpoints.
P708 Flow
Decimal
2
Set the number of decimal points required
in the flow rate display
P709 Flow
Cut Off
5.00%
Enter, as a percentage of maximum flow,
the minimum flow rate to be added to the
totaliser.
P830
mA Out
Range
2= 4 to 20
mA
What the mA output uses for the range.
0= Off, 1= 0 to 20 mA, 2= 4 to 20 mA,
3= 20 to 0 mA, 4= 20 to 4 mA.
P870
Fill Damping
32.80
feet/min
Rate of maximum fill rate (set above the
actual fill rate of the vessel).
P871
Empty
Damping
32.80
feet/min
Rate of maximum empty rate (set above
the actual empty rate of the vessel).
The default values used for determining the relay setpoints, when setting
Alarm relays, via the Quick Setup menu are entered as a % of span and are
as follows.
Relay Function
Alarm ID
On
Setpoint
Off
Setpoint
Alarm
Hi Hi
90%
85%
Alarm
High
85%
80%
Alarm
Low
10%
15%
Alarm
Lo Lo
5%
10%
