Enforcer: Programming Manual
Page: 38
Type Active Restore
LAST partition
partition
0021 Exit Starts Any
When exit time starts to set
FIRST area
At code entry to unset LAST
area
0022 Final Set Any When FIRST area is set
At code entry to unset LAST
area
0023 Strobe Set Fail
Works similar to output 016, but also fires if the set fail timer
expires.
0025 Keyswitch unset
This output turns on for 5 seconds when the system is disarmed
via a keyswitch input (pulsed or latched)
0026 Set with Omit Activates when inputs are omitted on setting
0028 Power Fault
Active during low volts and battery faults
*. Restores at code
entry after fault cleared.
0029 Confirmed Intruder Any
When more than one intruder
alarm activates
At next code entry
0030 Confirmed Hold Up Any
When more than one
confirmed hold up activates
At next code entry
0031 Entry Live during entry time
0032 Exit Live during exit time
0033 Entry/Exit Live during any entry or exit time
0034 Lights When exit or entry timer starts
20 seconds after set/unset
procedure completed
0035 Follow Input When input triggers Dependent upon programming
0037 Restore 1 At code entry to set After 3 seconds
0038 Restore 2
At code entry to set When unset
Re-triggers whenever an additional area is set
0039 PIR Latch 1 When set (and in Walk Test) At alarm, or when unset
0040 PIR Latch 2 This is the inverse polarity to PIR Latch 1
0041 Mains Good Output showing the mains is healthy
0042 Detr Indn Enable
This output activates during walk test and also when a code is
entered to view indications – staying activated for the time for
which the indications are viewed.
0043 Follow Test New output for alternative bell test by activating SAB
0044 Off During Test New output for alternative bell test by activating SAB
0048 Detr Walk Test
This output is active during walk test, and will only deactivate
when all detectors have been tested.
0049
Detector Masked
(Not applicable on grade 2
systems)
If any detector goes into
‘mask’ condition the output will
trigger
When masking fault clears.
0050 Follow 24 Hour
If any input programmed as
“Day alarm” activates
When input restored
0051 Comm Fault
When a commuinicator Fault
has signalled
When fault clears
0052 Mains Fail
After pre-set time without
mains power
On restoration of mains
0053 Battery Faults
When battery disconnected or
load fail detected
At next valid code entry
0054 Low Volts At fault When fault clears
0055
Global Fault 1
(Faults: Modem, Battery,
Activates if fault occurs only
when system is armed
When all faults cleared
To Next Page
