Enforcer: Programming Manual
Page: 39
Type Active Restore
Fuse, Line, Mains)
0056
Global Fault 2
(Faults: as above)
Activates if fault occurs at any
time
When all faults cleared
0057 German Relay For future use For future use
0058 Guard Code Used When ‘guard’ code accepted After 60 seconds
0059 Engineer Access When entering Engineer Mode Leaving Engineer Mode
0060 Initialise Digi At power up Live for 45 seconds only
0063 Test ATE/GSM
Test signalling through PSTN
and GSM. Activates when a
test call is sent.(only used for
specific GSMs)
When test completed
0064
Test ATS
For use with ATE complying
with BSIA Form 175 to
initiate test call to ARC by
each available path.
Test signalling through PSTN
and GSM. Activates when a
test call is sent.
When test completed
0065 Zone Activity Fail
If an input with NAT timer
active does not trigger in the
defined period
Next valid code entry
0066 ATE not used
Makes the ATE pin 5V or 0V depending if ATE outputs are
inverted
0170-
0199
User Defined
Can be used to triggers outputs via the keyfob. For example if an
output is programmed as type 0171 (Output 02) and is wired to
a garage door. And if a user has a keyfob programmed with
button 2 as Latched or Keyswitch Output (with Output 02
selected), then when the button is pressed the garage door will
open.
0600-0609 Timers 01-10: For future development
0610-0619 Calendar 01-20: For future development
0620-0639 Logic Gate 01-20: For future development
0640-0649 Delay 01-10: For future development
1xxx Follow input xxx
When input is
activated
When input clears
