ENFORCER V11 PROGRAMMING GUIDE
APPENDIX B  INPUT TYPES
NUMBER & TYPE OPERATION
00 Unused Factory default. Input is programmed out of operation.
01 Fire
Active at all times. Audible response: Full (dierentiated
Communicator: ‘Fire’ signal.
02 Gas
Active at all times. Audible Response: Full (dierentiated
Communicator: ‘Gas’ signal.
03 HU#
Active at all times. Audible Response: Full (dierentiated
Communicator: ‘Hold Up’ and ‘Input HU’ signals.
04 Silent HU#
Active at all times. Audible Response: None
Communicator: ‘Hold Up’ and ‘Input HU’ signals.
05 Tamper
When disarmed: Audible Response: Internal only Communicator:
‘Tamper’ signal. When set: Audible Response: Full (dierentiated)
Communicator: ‘Tamper’ and ‘Unconrmed’ signals.
06 Intruder
Active when set. Audible Response: Full
Communicator: ‘Intruder’ and ‘Unconrmed’ signals.
07 Final Exit (FX)#
Active when armed – initiates entry timer if system not disarmed
before entry time expires: Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconrmed’ signals.
08 Entry Route (ER)
Active when set, except during entry time.
Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconrmed’ signals.
09 ER (Part FX)
When fully armed (A), acts as Entry route input, as above. When part
armed (B,C,D), acts as Final Exit input, as above.
10 FX (Part ER)
When fully armed (A), acts as Final Exit input, as above. When part
armed (B,C,D), acts as Entry route input, as above.
11 PTS
Active during exit time to complete Arming procedure
No audible or communicator response.
Note: May be used to act as ‘doorbell’ by use of ‘chime’ attribute.
12 Switcher
Active at all times: This zone type is used to trigger an output or
task, but not an alarm. It will function whether the panel is armed
or disarmed and can be used to illuminate a light, or trigger a CCTV
camera etc.
If the zone has Masking or Tamper functions – then these will still
trigger an alarm, it is only regular activations that will not.
13 Day Alarm
When armed: Audible Response: Full; Communicator: ‘Instant’
signals. When disarmed: Audible Response: Programmable;
Communicator: ‘24hr Alarm’ signal (if programmed in Alarm
Responses menu).
16 Fault
When armed: Audible Response: Full; Communicator: ‘Instant’
signals. When disarmed: Audible Response: Programmable;
Communicator: ‘24hr Alarm’ signal (if programmed in Alarm
Responses menu).
20 Keyswitch Latched*
Accepts input from keyswitch (or equivalent) to arm/disarm the
Set modes assigned to it. Arming includes normal exit time, etc.
Requires latching action switch.
