BMC CONFIGURATION GROUP
4-44
Procedure:
1. In the LAN Destination Tab, choose the slot to be configured. This should be the
same slot that you have selected in the Alert Policy Entry?] Destination Selector
field. That is if you have chosen the Destination Selector as 4 in the Alert Policy Entry
page of Alert Policy Tab, then you have to configure the 4th slot of LAN Destination
Page.
2. Double click the slot and click Modify. This opens the Add LAN Destination entry.
Figure 4-30. Add LAN Destination entry Page
3. In the LAN Destination field, the destination for the newly configured entry is dis-
played and this is a read only field.
4. In the Destination Type field, select the one of the types.
5. In the Destination Address field, enter the destination address.
6. Select the User Name from the list of users.
7. In the Subject field, enter the subject.
8. In the Message field, enter the message.
9. Click Add to save the new LAN destination and return to LAN destination list.
10. Click Cancel to cancel the modification and return to LAN destination list.
11. In the LAN Destination Tab, to modify a configuration, select the row to be modi-
fied and click Modify.
12. In the LAN Destination Tab, to delete a configuration, select the slot and click
Delete.
Destination Address
If Destination type is SNMP Trap, then enter the IP address of the system
that will receive the alert. Destination address will support the follow-
ing:
IPv4 address format.
IPv6 address format.
Send Test Alert
These fields must be configured if email alert or SNMP Trap is chosen as
destination type. This field will send a test message in the message
field's content to specified destination.
Modify To modify existing LAN destination list.
Delete To delete LAN destination list.
Table 19: PEF Management - LAN Destination (Continued)
ITEM DESCRIPTION
