QCT QuantaMesh User Manual

Network Switch lnstallation Guide 23
QuantaMesh T3000 Series
Chassis for the T3048-LY9 Switch
Front panel
T3048-LY9
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PSU1 PSU2FAN
49
57
50
51
52
58
53 54
59 60
55 56
65 66
61 62
67 68
63 64
2 3
1 5 76
4
13 1214
8 9 1110
No. Item No. Item
1 10GBASE-T Ports 8 System info. LED
2 10GBASE-T Port LEDs 9 Console Port
3 QSFP+ Ports 10 Power LED
4 QSFP+ Port LEDs 11 Management Port
5 PSU1 LED 12 Link/Activity LED
6 Fan LED 13 USB Port
7 PSU2 LED 14 Speed LED
Rear panel
AC
DC
AC
DC
7069
1 5 1 10
97
8
6
24
3
24
3
No. Item No. Item
1
AC Power Connector (with Plug
Retainer)
6 Fan LEDs
2 PSU Warning LED 7 Hot-swappable Fan
3 PSU AC LED 8 QSFP+ Port LEDs
4 PSU DC LED 9 QSFP+ Ports
5 PSU2 10 PSU1
