QCT QuantaMesh User Manual

Network Switch lnstallation Guide 35
QuantaMesh T5000 Series
Ports of T5032-LY6
The switch chassis is equipped with the following ports:
• 32 QSFP+ ports (40-Gigabit Ethernet uplink ports)
• 1 Management ports
• 1 Console port
• 1 USB port
The chassis has 32 QSFP+ ports. Each of these ports uses an optical transceiver, active optical
cables, or direct-attached cable to connect the QSFP+ port to the hosts (uplink connections). For
more information on obtaining the appropriate QSFP+ modules, refer to “Supported Cables and
Transceivers” on page 35.
One management port enables you to manage the switch operation using an RJ-45 Ethernet
cable.
One console port enables you to perform the initial conguration by connecting to a PC with the
RJ-45 to DB-9 serial adapter cable.
*One USB port enables you to load the conguration les from a USB storage device to the
switch’s ash memory.
NOTE:
• *TheUSBportfunctionwillbesupportedinthefuturerelease.
Data Port Connection
Supported Cables and Transceivers
See the following table for the list of supported cables and transceivers.
Supported
Distance
Description Note
1m
40G Direct Attach Copper (DAC) cable QSFP+ to QSFP+
40G DAC Fan Out cable QSFP+ to 4 SFP+
3m
40G Direct Attach Copper (DAC) cable QSFP+ to QSFP+
40G DAC Fan Out cable QSFP+ to 4 SFP+
5m
40G Direct Attach Copper (DAC) cable QSFP+ to QSFP+
40G DAC Fan Out cable QSFP+ to 4 SFP+
7m 40G Active Optical Cable (AOC)
QSFP+ to QSFP+,
850 nm, MMF
10m 40G Active Optical Cable (AOC)
QSFP+ to QSFP+,
850 nm, MMF
20m 40G Active Optical Cable (AOC)
QSFP+ to QSFP+,
850 nm, MMF
> 20m 40GBASE-SR4 QSFP+ Transceiver Optic (MPO)
QSFP+, 850nm,
MMF
Up to 10km 40GBASE-LR4 QSFP+ Transceiver Optic (LC) QSFP+, SMF
NOTE:
• Formoreinformationaboutthecable/transceiver,pleasecontactQCTsales.
