QCT QuantaMesh User Manual

50 Network Switch Installation Guide
Appendix
The following pages in the appendix are showing the IP address conguration and rmware
upgrade SOP of Quanta runtime image.
Initial Conguration Process
When using the switch for the rst time, conguration must be carried out through a console.
Perform the following steps to congure the switch:
1 Connect a terminal to the console port.
2 Manually congure the IP Address by CLI.
3 Manage the switch.
Congure the IP Address
You can congure the switch with a static IP address or use a Dynamic Host Conguration
Protocol (DHCP) server to automatically obtain an IP address for the switch. For the rst time
conguration, it is recommended to set the IP address manually.
Set IP Address Manually
To set the IP address of the switch manually, perform the following:
1 Connect the switch to a computer with a terminal emulation program via the Console port.
2 On the terminal emulation program, select the appropriate serial port and set the following
congurations:
• Baud rate: 115200
• Data width: 8 bits
• Parity: None
• Stop bits: 1
• Flow control: None
3 After setting up the terminal, plug the power cable(s) to the AC power connector(s) of the
switch. The boot up screen appears in the terminal. The boot up process may take a few
minutes to complete.
4 When prompted for the User and Password, input “admin” for user and leave the password
empty, then press <Enter>.
5 On the prompt, input “congure”. The prompt changes to “(Quanta) (Cong) #”.
