Quantech QTC3040T User Manual

Quantech
63
Section 5: Technical data
Form QTC3-NM1
Issue date: 12/19/2023
55
QTC3 V Hz MCA Min. N/F
disc SW
Min. dual
elem. fuse
and CB
Max. dual
elem. CB
System 2
Compr. 1 Compr. 2 Compr. 3 Std. ow fans
RLA LRA RLA LRA RLA LRA Qty. FLA LRA
3095T
208 60 450 600 500 500 106.2 523 106.2 523
— —
3 7.6 44
230 60 449 600 500 500 106.2 578 106.2 578 — — 3 7.4 37
380 60 260 400 300 300 64.3 355 64.3 355 — — 3 4.5 23.1
460 60 220 250 250 250 53.1 290 53.1 290 — — 3 4 19
575 60 175 200 200 200 42.5 255 42.5 255
— —
3 2.9 15.3
3100T
208 60 458 600 500 500 106.2 523 106.2 523
— —
4 7.6 44
230 60 456 600 500 500 106.2 578 106.2 578 — — 4 7.4 37
380 60 264 400 300 300 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 224 250 250 250 53.1 290 53.1 290 — — 4 4 19
575 60 178 200 200 200 42.5 255 42.5 255
— —
4 2.9 15.3
3110T
208 60 497 600 600 600 106.2 523 106.2 523
— —
3 7.6 44
230 60 496 600 600 600 106.2 578 106.2 578 — — 3 7.4 37
380 60 300 400 350 350 64.3 355 64.3 355 — — 3 4.5 23.1
460 60 250 400 300 300 53.1 290 53.1 290 — — 3 4 19
575 60 198 250 225 225 42.5 255 42.5 255
— —
3 2.9 15.3
3120T
208 60 512 600 600 600 106.2 523 106.2 523
— —
4 7.6 44
230 60 511 600 600 600 106.2 578 106.2 578 — — 4 7.4 37
380 60 309 400 350 350 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 258 400 300 300 53.1 290 53.1 290 — — 4 4 19
575 60 204 250 225 225 42.5 255 42.5 255
— —
4 2.9 15.3
3125T
208 60 579 800 600 600 57.7 284 57.7 284 57.7 284 4 7.6 44
230 60 577 800 600 600 57.7 330 57.7 330 57.7 330 4 7.4 37
380 60 338 400 400 400 30.9 192 30.9 192 30.9 192 4 4.5 23.1
460 60 285 400 300 300 26.9 180 26.9 180 26.9 180 4 4 19
575 60 226 250 250 250 21.5 132 21.5 132 21.5 132 4 2.9 15.3
3130T
208 60 555 800 600 600 106.2 523 106.2 523
— —
4 7.6 44
230 60 553 800 600 600 106.2 578 106.2 578 — — 4 7.4 37
380 60 329 400 350 350 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 274 400 300 300 53.1 290 53.1 290 — — 4 4 19
575 60 217 400 250 250 42.5 255 42.5 255
— —
4 2.9 15.3
3140T
208 60 618 800 700 700 106.2 523 106.2 523
— —
4 7.6 44
230 60 617 800 700 700 106.2 578 106.2 578 — — 4 7.4 37
380 60 374 400 400 400 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 311 400 350 350 53.1 290 53.1 290 — — 4 4 19
575 60 246 400 300 300 42.5 255 42.5 255
— —
4 2.9 15.3
3150T
208 60 634 800 700 700 106.2 523 106.2 523
— —
4 7.6 44
230 60 632 800 700 700 106.2 578 106.2 578 — — 4 7.4 37
380 60 383 400 400 400 64.3 355 64.3 355 — — 4 4.5 23.1
460 60 319 400 350 350 53.1 290 53.1 290 — — 4 4 19
575 60 252 400 300 300 42.5 255 42.5 255
— —
4 2.9 15.3
Table 11: Electrical data without pumps, R-410A, continued
Notes:
• Reference PIN 59 for pump models.
• Use this table along with Table 9 on page 58 to determine electrical data of the unit plus the pump.
• Does not include the control transformer.
