Quantech QTC3040T User Manual

Quantech
64
Form QTC3-NM1
Issue date: 12/19/2023
Section 5: Technical data
Table 11: Electrical data without pumps, R-410A, continued
QTC3 V Hz MCA Min. N/F
disc SW
Min. dual
elem. fuse
and CB
Max. dual
elem. CB
System 2
Compr. 1 Compr. 2 Compr. 3 Std. ow fans
RLA LRA RLA LRA RLA LRA Qty. FLA LRA
3160T
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
3170T
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
3205T
208 60 734 1,000 800 800 102.8 574 102.8 574 102.8 574 6 7.6 44
230 60 731 1,000 800 800 102.8 635 102.8 635 102.8 635 6 7.4 37
380 60 443 600 500 500 62.2 355 62.2 355 62.2 355 6 4.5 23.1
460 60 369 600 400 400 51.4 280 51.4 280 51.4 280 6 4 19
575 60 292 400 300 300 41.1 225 41.1 225 41.1 225 6 2.9 15.3
3225T
208 60 959 1,200 1,000 1,000 138.8 943 138.8 943 138.8 943 6 7.6 44
230 60 956 1,200 1,000 1,000 138.8 943 138.8 943 138.8 943 6 7.4 37
380 60 599 800 600 600 87.2 564 87.2 564 87.2 564 6 4.5 23.1
460 60 504 600 600 600 73 408 73 408 73 408 6 4 19
575 60 359 600 400 400 51.9 375 51.9 375 51.9 375 6 2.9 15.3
Notes:
• Reference PIN 59 for pump models.
• Use this table along with Table 9 on page 58 to determine electrical data of the unit plus the pump.
• Does not include the control transformer.
