Communication Protocol USB Port Cable Pin Assignments
CubiScan 125 Service Manual 58
The following table shows the parameters for the default Ethernet port settings.
The Ethernet port can be configured via this command set or through the touch interface.
Commands exist to configure the Port, IP address, Subnet address and Gateway address.
Ethernet port configuration (TCP) commands may be sent via the PC/COM (RS-232) or USB
ports, but NOT the Ethernet port.
The following lists show the files available for TFTP binaries.
Files available for TFTP binary GET.
• cs125img.bmp
• cs125imz.bmp
• cs125isc.bmp
• param125.txt
Files available for TFTP binary PUT.
• param125new.txt
• cs125.bin
USB Port Cable Pin Assignments
The CubiScan 125 includes a USB 2.0 type B connector, as shown below.
The following table shows the USB 2.0 type B connector pin assignments.
7 NC No Connection
8 NC No Connection
Ethernet Port (default settings)
IP Address
DHCP or Static (Default static
10.1.100.100)
IP Com Port 1050
TFTP Port 69
USB 2.0 type B Connector Pin Assignments
Pin Name
Cable
Color
Description
