Technical Specificat
ions
133
Operation
CP
-3211-
18
x
CP
-4221-
20
x
CP
-4221-301
Languages
English, German, French
, Italian, Simplified
Chinese, Trad
itional
Chinese, Russian, and
Korean
MicroSD Card Recordin
g
microSD/SDHC 32GB sup
port
PTZ Operation
Manual Speed
0.5° ~ 90°/second
Pan Travel
360° endless
Tilt Travel
-10° ~ 190°
Presets
256
Preset Accuracy
0.225°
Preset Speed
5° ~ 400°/second
Sequence
8
Auto Pan
4
Pattern
4
Proportional Pan &
Tilt
On/Off (pan and tilt speed
proportional to zoom
ratio)
Resume after Power
Loss
Yes
Home Function
Preset, Sequence, Au
to pan, Pattern
Auto Flip
Digital/Mechanical/Off
Motion Detection
On/Off
Image Rotation
Flip/Mirror/In
verse/Portrait
Network
Ethernet
10/100 MB Ethern
et (RJ45)
Network Prot
ocols
IPv4/v6, TCP/IP,
UDP, RTP, RTSP, H
TTP, HTTPS, ICMP, FTP, S
MTP, DHCP,
PPPoE, UPnP, IG
MP, SNMP, QoS, IEEE
802.1x, ONVIF
Password Levels
User and Administrat
or
Security
User Account and Pass
word Protection
Internet Browsers
IE
7, 8, and 9
IE
7, 8, 9, and 10
147
149
Table of Contents
Default Chapter
2
Table of Contents
2
Revision History
8
1 Document Information
10
2 Overview
16
Features
16
Package Contents
17
Figure 1: Indoor Package Contents
17
Figure 2: Outdoor Package Contents
18
3 Introduction to the Quasar HD PTZ Camera
20
Quasar HD PTZ Indoor Camera Dimensions
20
Quasar HD PTZ Outdoor Camera Dimensions
20
Figure 3: Indoor Camera Dimensions
20
Figure 4: Outdoor Camera Dimensions
20
Camera Connectors
21
Figure 5: Indoor/Outdoor Connector Locations
21
4 System Requirements
24
5 Installation
26
Indoor Installation
26
Outdoor Installation
26
Power and Ethernet Cable Connection
27
Initial Camera Configuration
27
Figure 6: Discovered IP Devices
28
Figure 7: Assign IP Dialog Box
28
Preparing the Camera for Mounting
29
Mounting Instructions
29
Ceiling Mount
29
Figure 8: Ceiling Mounting: Straight Tube + Mount Kit
38
Figure 9: Swan Tube Mounting
39
Wall Mount
40
Figure 10: Wall Mount: Compact Wall Mount + Mount Kit
41
Figure 11: Wall Mount: Standard Wall Mount + Mount Kit
42
Corner Mount
43
Figure 12: Wall Box Mounting: Wall Box Mount + Standard Wall Mount + Mount Kit
43
Figure 13: Corner Wall Mounting: Corner Standard/Mini Mounting Plate + Standard Wall Mount + Mount Kit
45
Figure 14: Corner Box Mounting: Corner Thin/Wide Box + Standard Wall Mount + Mount Kit
46
Pole Mount
47
Figure 15: Pole Direct Mounting: Pole Thin/Wide Direct Mounting + Standard Wall Mount + Mount Kit
48
Figure 16: Pole Box Mounting: Pole Thin/Wide Box + Standard Wall Mount + Hard Ceiling Mount
49
6 Using the DNA Utility to Search and Access the Camera
50
Introduction
50
Quick Start
51
Main Screen
51
Navigation Bar
51
Figure 17: DNA Main Screen
51
Context Menu
52
Figure 18: Context Menu
52
Configuring Communication Settings on the Quasar Camera
53
Figure 19: Windows Firewall Screen
53
Figure 20: Discovered IP Devices
53
Figure 21: DNA Assign IP - Use DHCP Dialog Box
54
Figure 22: DNA Assign IP - Static IP Dialog Box
54
Figure 23: Installing the Activex Control
55
Figure 24: Security Window
55
Adjusting and Framing-Up the Camera View
56
7 Configuration and Operation
58
Browser-Based Viewer Introduction
58
Figure 25: Quasar Browser-Based User Interface
58
Home Page
60
CP-3211/CP-4221 Camera Home Page
60
Figure 26: Info Pop-Up Screen
60
Figure 27: Home Page Function Buttons
60
System-Related Settings
64
System
64
Figure 28: System Screen
64
Security
65
Figure 29: System Configuration - Security Screen
65
Figure 30: System Configuration - User Screen
66
Figure 31: Editing Password and Privileges
67
Figure 32: Modifying Account Authority
67
Figure 33: HTTPS Screen
68
Figure 34: HTTPS Screen - Create Self-Signed Certificate
69
Figure 35: HTTPS Screen - Install Signed Certificate
69
Figure 36: HTTPS Screen - Upload Signed Certificate
70
Figure 37: Example of Self-Signed Certificate
70
Figure 38: Self-Signed Certificate - Details
71
Figure 39: IP Filter Screen
72
Figure 40: Enabling the IEEE 802.1X Protocol
73
Network
74
Figure 41: Network Screen
74
Figure 42: Network Qos Screen - DSCP Settings
76
Figure 43: SNMP Settings Screen
77
Figure 44: Network Screen - Upnp Settings
78
Figure 45: Direct Access to Camera with Upnp Enabled
79
Ddns
80
Figure 46: DDNS Screen
80
Mail
81
Figure 47: Mail Screen - SMTP
81
Ftp
82
Figure 48: FTP Screen
82
Http
83
Figure 49: HTTP Screen
83
Application
84
Figure 50: Application Screen
84
Figure 51: Application Screen - Alarm Pin Selection
85
Figure 52: Application Screen - by Schedule
85
Figure 53: Application Screen - Drop-Down Menu Schedule Selection
86
Figure 54: Application - Record Stream to SD Card
87
Figure 55: Application -Upload Image by FTP
88
Figure 56: Application - Upload Image by E-Mail
88
Figure 57: Application - PTZ Parameters
89
Motion Detection
91
Figure 61: Record Stream to SD Card Option
93
Figure 62: Upload Image by FTP Option
94
Network Failure Detection
95
Storage Management
97
Figure 68: Video File Recording List
98
Recording
99
Schedule
100
File Location
101
View Information
102
Figure 74: User Information Screen
103
Figure 76: Parameter List Screen
104
Factory Default
105
Software Version
106
Software Upgrade
107
Maintenance
108
Figure 84: File Download Screen
109
Video and Audio Streaming Settings
110
Video Format
110
Figure 86: Video Rotate Type Drop-Down Menu
115
Figure 87: View-1 (Source)
116
Video Compression
117
Video OCX Protocol
119
Video Frame Rate
121
Audio
122
PTZ Settings
123
Preset
124
Pattern
124
Auto Pan
125
Sequence
126
Figure 98: Sequence Set Screen
127
Home
128
Tilt Range
129
Privacy Mask
130
Exposure
131
Figure 103: CP-4221-301 Exposure Screen
132
Figure 104: CP-4221-301 White Balance Screen
133
Camera - WB (White Balance)
133
Figure 105: White Balance Screen (All Units Except CP-4221-301)
134
Camera - Misc1 (Miscellaneous Settings Menu 1)
136
Camera - Misc2 (Miscellaneous Settings Menu 2)
140
Logout
144
Appendices
146
Technical Specifications
147
A.1. Technical Specifications
147
Device Search Software
150
Initial Camera Configuration
150
Searching and Accessing the Camera with Device Search
151
Configuring Communication Settings of a Quasar Camera
151
Figure 114: Windows Security Alert
152
Figure 117: Security Warning Window
154
Internet Security Settings
155
Figure 121: Schedule Screen
156
Install Upnp Components
157
Deleting the Existing Dcviewer
159
Deleting Temporary Internet Files
160
Connecting Leads to a Spring Clamp Terminal Block
161
Camera and Mounting Accessories
162
Contacting DVTEL
169
