Configuration and Op
eration
49
7.3
System-Related Settings
The figure below sho
ws all categ
ories under the
System
tab. Each cat
egory in the sideb
ar is
explained in the foll
owing sections.
Note:
The
System
configurati
on page is accessible
only by the Admin
istrator.
Figure
28
: System Screen
Related Links
System
Security
Network
DDNS
Mail
FTP
HTTP
Application
Motion Detection
Network Failure
Detection
Storage Managemen
t
Recording
Schedule
File Location
View Information
Factory Default
Software Version
Software Upgrade
Maintenance
7.3.1
System
Click the
System
tab
in the sidebar. The
System
pag
e is displayed in Figure
28
: System Screen. It
includes the foll
owing details:
Host Name
The host name is for
camera identificati
on. If the alarm function is enab
led and is set to send an
alarm message b
y Mail/FTP, the h
ost name entered here is displ
ayed in the alar
m message. See
Application
.
63
65
