Configuration and Operation
83
Disk cleanup setting
Enable automatic recording cleanup by selecting Enable automatic disk cleanup. From the pull-down
menu, specify the minimum length of time over which to remove recordings. For example, remove
recordings over 10 days old. Enter the percent of disk capacity used in order to remove the oldest
recordings. Click Save when finished.
Recording List
Each video file on the microSD/SDHC card is listed in the Recording list below. The maximum file size
is 60 MB per file. See Recording for further details.
When the recording mode is set as Always (consecutive recording) and the microSD/SDHC card
recording is enabled by events triggered, the system immediately saves a recorded event on the
memory card once an event occurs. Then the camera will return to the regular recording mode after
events recording.
Figure 68: Video File Recording List
Remove – To remove a file, first select the file and then click Remove.
Sort – Click Sort to list the files in the Recording list in order of name and date.
The capital letters: R, N, A, (A0), M, (M0) followed by an underscore, appear at
the beginning of the file name. They denote the type of recording.
R - Regular (always or schedule)
N - Network failure
M - Motion, (M0 refers to the first motion window trigger)
A - Alarm (A0 refers to the first alarm trigger input).
