Introduction to the Quasar HD PTZ Camera
5
3 Introduction to the Quasar HD PTZ Camera
This chapter provides the camera’s dimensions for reference before installation. The definition of
each connector on the camera’s back plate is also specified.
Related Links
 Quasar HD PTZ Indoor Camera Dimensions
 Quasar HD PTZ Outdoor Camera Dimensions
 Camera Connectors
 Technical Specifications
3.1 Quasar HD PTZ Indoor Camera Dimensions
The Quasar HD PTZ indoor camera’s dimensions are shown below.
Top View
Side View
Figure 3: Indoor Camera Dimensions
3.2 Quasar HD PTZ Outdoor Camera Dimensions
The Quasar HD PTZ outdoor camera’s dimensions are shown below.
Top View
Side View
Figure 4: Outdoor Camera Dimensions
