Quasar CP-3211/CP-4221 User and Installation Guide
18
3. Loosen the wings from the recessed bracket by turning each wing’s center screw counter-
clockwise (as indicated in the first figure below), until the wings are able to swing outward (as
shown in the second figure below).
4. Place the ceiling sticker on the ceiling, and cut the circle part out of the ceiling.
5. With the wings facing inward, place the winged recessed bracket into the ceiling opening.
6. Insert a hand into the center of the recessed bracket and rotate the wings to face outward.
