Installation
29
Corner standard mounting package contents:
M8x16 screw x4
Spring washer 8 x4
Washer 8 x4
M8 Nut x4
Sponge x2
Tools required:
Drill
Phillips and flat-head screw drivers
To install the standard/compact wall mount with corner/corner mini mount:
1. Cut a cable access hole in the wall.
2. Attach the corner mounting plate to the wall using the appropriate screws and screw anchors
(not provided).
3. Thread the cables through the corner mounting plate.
4. Attach the standard/compact wall mount to the corner mount using the supplied screws and
washers.
5. Thread the cables through the standard/compact wall mount with the cables coming out of
the pendant mount’s outlet. For outdoor cameras, attach the waterproof gasket to the
pendant mount.
6. After threading the cables, block the entry hole with the supplied sponge to prevent insects
from entering. See Standard or Compact Wall Mount, Step 3.
7. Thread the cables through the indoor or outdoor mount kit and attach the mount kit to the
standard/compact wall mount using the supplied screws and washers.
8. For outdoor cameras, adjust the waterproof gasket to the joint.
9. Connect the cables to the camera.
10. Secure the camera to the indoor or outdoor mount kit.
11. Ensure the camera is fixed completely, and that the thread holes on the camera’s fixing plate
and the mount kit are aligned.
12. Screw in the supplied screw and washer.
