Configuration and Operation
81
To select a schedule:
1. Select By schedule. The message Please Select is displayed.
2. Click Please select. A drop-down menu opens.
3. From the drop-down menu, select a schedule from 1 to 10. The selected schedules are
displayed in a horizontal field above the drop-down menu.
For instructions how to set a schedule for network failure detection, refer to Schedule.
Detection Type
In the text box, enter the IP address to ping and the time interval in minutes between pings.
Triggered Action
The Administrator can specify various alarm actions to be taken when an alarm is triggered. The
options are listed below.
Enable alarm output 1/Enable alarm output 2 – Select these boxes to enable alarm relay
outputs.
Record stream to sd card – Select this box in order to save the alarm-triggered recording into
a microSD/SDHC card. Enter the number of seconds for the pre-trigger buffer. Select the first
radial button to upload for a specified length of time and enter the number of seconds.
Alternatively, select the second radial button to upload during the active trigger.
Figure 66: Network Failure Detection Screen – Triggered Action
Make sure the local recording (with microSD/SDHC card) is activated so that this
function can be implemented. See Recording for further details.
Send Message by FTP/E-Mail – Select whether to send an alarm message by FTP and/or
e-mail when motion is detected.
