Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 45 / 56
Table 29: GNSS Current Consumption of EP06-E
LTE-FDD B1+B28 @ 23.2 dBm
920.3
mA
LTE-FDD B3+B3 @ 23.37 dBm
986.8
mA
LTE-FDD B3+B5 @ 23.1 dBm
1010.7
mA
LTE-FDD B3+B7 @ 22.9 dBm
1046.8
mA
LTE-FDD B3+B8 @ 22.8 dBm
1017.1
mA
LTE-FDD B3+B20 @ 22.7 dBm
1060.8
mA
LTE-FDD B3+B28 @ 22.6 dBm
1079.3
mA
LTE-FDD B7+B5 @ 23.3 dBm
991.3
mA
LTE-FDD B7+B7 @ 23.3 dBm
1022.2
mA
LTE-FDD B7+B8 @ 23.3 dBm
1030.9
mA
LTE-FDD B7+B20 @ 23.3 dBm
1095.8
mA
LTE-FDD B7+B28 @ 23.2 dBm
1111.2
mA
LTE-FDD B20+B32 @ 23.2 dBm
805.65
mA
LTE-TDD B38+B38 @ 23.1 dBm
530.68
mA
LTE-TDD B40+B40 @ 22.7 dBm
462.23
mA
LTE-TDD B41+B41 @ 23.4 dBm
506.37
mA
WCDMA
voice call
WCDMA B1 CH10700 @ 23.2 dBm
622.18
mA
WCDMA B3 CH1122 @ 23.2 dBm
862.14
mA
WCDMA B5 CH4408 @ 22.9 dBm
611.89
mA
WCDMA B8 CH3012 @ 22.9 dBm
699.91
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
(GNSS)
Searching
(AT+CFUN=0)
Cold state @ Passive Antenna
60.77
mA
Lost state @ Passive Antenna
60.5
mA
Tracking
(AT+CFUN=0)
Instrument environment
36.05
mA
