Quectel EP06 Series User Manual

LTE-A Module Series
EP06 Series Hardware Design
EP06_Series_Hardware_Design 46 / 56
The following table shows the current consumption of EP06-A.
Table 30: EP06-A Current Consumption
Open Sky @ Passive Antenna
TBD
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
1.88
mA
WCDMA PF=64 (USB disconnected)
2.4
mA
WCDMA PF=128 (USB disconnected)
2.29
mA
WCDMA PF=256 (USB disconnected)
2.29
mA
WCDMA PF=512 (USB disconnected)
2.28
mA
LTE-FDD PF=32 (USB disconnected)
3.5
mA
LTE-FDD PF=64 (USB disconnected)
3.47
mA
LTE-FDD PF=128 (USB disconnected)
3.5
mA
LTE-FDD PF=256 (USB disconnected)
3.49
mA
LTE-TDD PF=32 (USB disconnected)
3.67
mA
LTE-TDD PF=64 (USB disconnected)
3.6
mA
LTE-TDD PF=128 (USB disconnected)
3.2
mA
LTE-TDD PF=256 (USB disconnected)
3.54
mA
Idle state
WCDMA PF=64 (USB disconnected)
21.2
mA
WCDMA PF=64 (USB connected)
31.3
mA
LTE-FDD PF=64 (USB disconnected)
22.7
mA
LTE-FDD PF=64 (USB connected)
31.1
mA
LTE-TDD PF=64 (USB disconnected)
23.9
mA
LTE-TDD PF=64 (USB connected)
31.2
mA
WCDMA data
WCDMA B2 HSDPA CH9400 @ 23.1 dBm
563.4
mA
