Figure 7-60
Please refer to the following sheet for detailed information:
This is to set device name.
This is device channel number.
You can select the language from the dropdown list.
Please note the device needs to reboot to get the modification
activated.
This is to display video standard such as PAL.
Here is for you to select working mode when hard disk is full. There
are two options: stop recording or rewrite. If current working HDD is
overwritten or the current HDD is full while the next HDD is no
empty, then system stops recording, If the current HDD is full and
then next HDD is not empty, then system overwrites the previous
files.
Here is for you to specify record duration. The value ranges from 1
to 120 minutes. Default value is 60 minutes.
7.8.5.1.2 Date and time
The date and time interface is shown as in Figure 7-61
