Racepak
30402 Esperanza, Rancho Santa Margarita, CA 92688 USA
Phone: 949-709-5555 Fax: 949-709-5556 www.racepak.com
7
SmartWire with Data Recorder
If utilizing the SmartWire unit with any of the compatible Racepak Data Recorders (i.e. connected via V-Net to
compatible Racepak data recorders), the same car configuration file utilized to program the data recorder will be
also be utilized to program the SmartWire. The SmartWire will need to be synced into the existing car
configuration file. Once READ in (synced), channel buttons for the SmartWire unit will appear in the data
recorder configuration file.
1. Connect PC to data recorder using the programming cable supplied with data
recorder system.
2. Ensure the main power is turned on for both the SmartWire AND data recorder.
The Power light on the SmartWire should be lit Red.
3. Start the DatalinkII program by double clicking on the DatalinkII
Program icon located on the Windows desktop of PC.
4. Open the car configuration file. To open the car configuration file, select File
located in the main menu bar across the top of the screen, and select Open
Car Configuration. (shown right).
5. The dialog box shown below will be displayed.
6. The list on the left-hand side of the Select Configuration dialog
box will display all of the file folders in the RacePakData
subdirectory (C:\RacePakData) that contain valid configuration files
with a .rcg file extension. Select the item that matches data
recorders serial number by left clicking on it with the mouse
(shown in example is V300SD_4447).
7. The list on the right will now show the list of configuration files contained in this folder. Select the item
which matches the data recorder serial number by left clicking, then the OK button.
