Racepak
30402 Esperanza, Rancho Santa Margarita, CA 92688 USA
Phone: 949-709-5555 Fax: 949-709-5556 www.racepak.com
1
Technical Specifications
Output Capacity: 125 Amps
Current Consumption: 180 mA typical operation (<1 mA in shutdown mode)
Min/Max Power Supply: 8-20 Volts
Operating Power Supply: 12-16 volt automotive applications.
Inputs: 12 hardwired direct (voltage triggered (>2.7V) or ground triggered (<2.5V)
Outputs: 30 (8 outputs @ 20 Amps, 22 outputs @ 10Amps)
Response: 3.0 milliseconds max.
Programming: USB (or via V-Net when used with a V-Net data recorder)
Dimensions: Length 6.5” (16.51 cm), Width 5.5” (13.97 cm), Height 2.0” (5.08 cm)
Weight: 25.8 ounces (731.4 grams)
Note: All current ratings are for 12 volt operation. For 16 volt systems, subtract 25 percent.
Connections:
• Two - 23 pin Ampseal, (hardwired direct inputs, outputs, grounds and shutdown pin)
• One - 1/4”x 20 Main Stud, (main power supply)
• One USB mini (programming when utilized without a compatible data recorder)
• One Switch CAN bus (connection for optional Switch Panel and/or Switch Module)
• One V-Net CAN bus (connection for optional V-Net sensors and/or compatible data recorders)
Outputs are:
• Monitored for Current, Voltage, and Status
• Protected via user settable limits for over-current situations
• Protected from short circuits and/or thermal overload situations
• Function programmable as:
o Constant On
o Flash
o Latch On
o Single Pulse
o Windshield Wiper (only available on channel 19)
• Time Delayed for On or Off
• Outputs are controlled via any combinations of:
o Switchable inputs
o Programmed logic operations;
(Equal to, Not Equal to, Greater than, Greater than or Equal to, Less than, Less than or
Not Equal to)
o V-Net attached sensors (Temperatures, Pressures, RPM, etc.)
o Other Outputs
