11. In order to activate this output, the previously configured Setpoint Control Channel must be added to the
Logic area on the right area of the window. To add this channel to control the output, Right-click in
LOGIC area and select it. If multiple Setpoint Control Channels are configured, they will show up when
right-clicked. Be sure to select the desired selection.
12. Once these values are set, we can send this change to the SmartWire by clicking the OK button on the
On/Off Condition window. This will return to the output channel window.
13. Within the output channel window, click the “SEND Configuration” button in the lower right area of the
window.
14. Once completed, the message log window will show “DEVICES PROGRAMMED SUCCESSFULLY”
15. Click OK to return to the output channel window.
Understanding Basic Logic Flow:
• Logic conditions are added or removed by right clicking in the Logic area.
• Basic flow of the Logic area is:
IF
“Channel X”
“&”
“Channel Y” are both true, activate output
OR
IF
“Channel Z” is true, activate output
• The “&” connects two logic conditions together meaning both would have to be True in order for the
output channel to be activated.
• The “OR” separates the logic conditions.
If any Logic condition is True, the output channel condition would then become True and output channel would
be activated.
To Next Page
