Racepak
30402 Esperanza, Rancho Santa Margarita, CA 92688 USA
Phone: 949-709-5555 Fax: 949-709-5556 www.racepak.com
13
• Supply Switch Bus Power When: This setting is used to manage if/when the switch port receives
power from the SmartWire unit. This manages the power to the items connected to the switch port on
the SmartWire unit. Default= Always On
• VNET Bus Gateway: Default=On DO NOT CHANGE-FOR ADVANCED USERS ONLY!
• Internal Temp Units: Determines unit of measure for the internal temperature sensor when logged.
Default= °F
• Real-Time Telemetering Setup (Graph View): To perform a Real-Time graphing, channels must be
selected and sent to the SmartWire unit using the Real-Time Telemetering Setup windows. (See Real-
Time Viewing section)
Buttons (lower right of window):
• Start All Channels Live Data (List View): When a real-time graph is not required, this button can be
selected to show a real-time list of channels. Shows SmartWire outputs and hardwired inputs only.
• Start Channel Live Data: Shows real-time data for this one particular window.
• Send Configuration: Sends the windows current values of this channel to the SmartWire
• Read Configuration: Reads the values from the SmartWire and populates the window with the
currently programmed values of this channel.
