RadioLink Crossflight User Manual

Radiolink Electronic Ltd
www.radiolink.com
5
Specifications
Weight & Dimension
Dimension
39.7*39.7*12.1mm
(1.56"*1.56"*0.48")
Weight
16.5g (0.58oz), 54g (1.9oz when all the
connect wires included)
Hardware
Processor
HC32F4A0PITB
Sensor
Gyro
ICM42670
Compass
VCM5883L
Barometer
LPS22HB
FRAM
Without FRAM, use the internal flash
to store parameters, 2617 waypoints
for multi-copters, and 2623 waypoints
for airplanes, cars, and boats.
Buzzer
1
Safety Switch
None
Connector
JST GH 1.25 Connector
PWM Output
10 PWM output
Mavlink UART
2 (Without CTSRTS)
USB Port
1 (Type-C)
GPS UART / I2C Port
1
RC In Signal Input
PPM/SBUS
RSSI Output
Support
OSD Module
OSD Module integrated
ESC Protocol
PWM
DShot Protocol
Do not support
OneShot Protocol
Do not support
RTK
Support
Power Module
Specifications
Input Voltage
2-12S
Input Current
90A
Output Voltage
5.1V
Output Current (BEC)
2.5A
Input Current (connect to one
ESC only)
20A
Adaptable Models
Airplane/3-8 Copters/Helicopter/Car/Boat/Submarine/Radartracker
