33
IQ Network Communication Cartridge
E
The IQNet Ping screen is
displayed. Use the + and -
buttons to select any Client
address. Press Ping to check the
communication status.
The LCD will display Response-
Yes if the ping is successful, or
No for an unsuccessful ping.
The amount of time until the
response was received from
the client satellite is listed in
milliseconds.
Client Satellite Controllers
To display the status of Client
Satellites with any cartridge
installed:
g
Turn the controller dial to
ETM/IQ SETTINGS
A
The IQ Settings main menu is
displayed. Use the UP or DOWN
arrows to select Status; press
Next.
NCC Configurator
B
The Satellite Status screen is
displayed. Current status of IQ,
Radio, and CM ports are shown.
