Rain Bird IQ - Figure 2 - Installation Overview

5
IQ Network Communication Cartridge
Figure 2 - Installation Overview
3
A
ESP-LX Controller Front Panel
B
IQ Network Communication
Cartridge (IQ-NCC-EN shown)
C
Connection Module (CM) Cable
(CM Y-Cable shown)
a. To IQNet Radio Modem
b. To Connection Module
D
IQ Port Cable (or Antenna)
E
Ground Wire (to earth ground)
F
IQNet PE Communication
Cable to other Satellites
G
Connection Module
(FSCM-LXME shown)
3
4
5
6
3
7
1
2
b.
a.
