Special equipment
103
7
7 Special equipment
No. Illustration Designation
1 Level sensor for AXIS/MDS
2 Forward speed sensor for
QUANTRON-A
3 Y cable RS232 for data exchange (e.g.
GPS, N sensor, etc.)
4 System tractor cable set for
QUANTRON-A
12m AXIS
