Attachment and installation
21
3
3.3 Connecting the control unit
Depending on the equipment, there are different methods of attaching the control
unit to the fertilizer spreader. Schematic connection diagrams:
for standard connection, see page 22,
for connection to the wheel sensor, see page 23,
for connection to the wheel sensor and machine cable, see page 24.
Proceed in the following order.
Select a suitable position in the tractor cabin (within the driver's field of vi-
sion) to fix the control unit.
Fix the control unit by means of brackets in the tractor cabin.
Connect the control unit to the 7 pin socket or to the forward speed sensor
(depending on configuration).
Connect the control unit to the actuators of the machine using the 39-pin ma-
chine cable.
Connect the control unit to the tractor's power supply using the 3-pin plug con-
nector.
NOTICE
After the control unit has been switched on, QUANTRON-A the display shows
the machine number for a short time.
NOTICE
Note the machine number
The control unit QUANTRON-A is factory-calibrated for the fertiliser spreader
with which it has been delivered.
Only connect the control unit to the correct fertiliser spreader.
