23
16. Press Next . The Distance: Hitch Offset From Center window will open.
17. Enter the distance from the center of the machine to the center of the hitch.
NOTE: This allows the CRX to calculate the correct position of the implement
for determining the coverage rate and boom control functions.
18. Select if the distance is to the Left or Right of the axle.
19. Press Next . The Distance: Rear Axle to Hitch window will open.
20.Enter the Distance from the rear axle to the hitch.
NOTE: If a Tracked Machine, enter the Distance from the track center to the
hitch.
21. Press Accept .
DELETING AN EXISTING MACHINE
To delete an existing machine:
1. Press Machine on the CRX settings screen.
2. Select the desired machine.
3. Press Delete . The Confirm Delete Machine window will open.
4. Select Accept to delete the machine or cancel to return to the Select
Machine window.
CREATING A MOUNTED IMPLEMENT
To create a new implement that is mounted to the frame structure or the machine:
1. On the settings page, press the Machine button. The Machine
Configuration window will open.
2. Press the Edit icon. Either modify the existing machine or select an implement to
mount to an existing machine.
