RUN SCREEN OVERVIEW
The image below is an example of a run screen. This section provides basic
information on run screen layout and widgets.
RUN SCREEN OVERVIEW
SIDE BAR ICONS
There are many side bar icons available on the run screen. The table below shows
the widget image as well as a brief description of function. Run screen configuration
will vary by device and settings.
Icon Function Description
AB Contour
Indicates that the currently selected line is
an AB Contour.
AB Heading Allows the user to enter a GPS heading.
AB Load Load an AB guidance line.
Guidance Lines Start or load a new guidance line.
Last Pass Create a Last Pass line with this widget.
Pivot
Create an pivot guidance line with this
widget.
Side Bar
Icons
Side Bar
Icons
