50
MASTER SWITCH CONFIGURATION
1. Press Master Switch on the CRX Settings screen. The Master Switch Control
Configuration window will open.
2. If desired, select the Require All On checkbox. This requires all selected inputs to
be On for the Master to be on. Otherwise only one selected input needs to be on.
3. The default for On-Screen checkbox is selected.
NOTE: Aux Input - Select this option if there is a wired switch to the CRX Aux
Input wire to act as a master switch.
AccuBoom - Select this option if there is a wired switch on the
AccuBoom cabling orange wire to act as a master switch.
Steering - Select this option if you want the SmarTrax to record data
only when steering is engaged.
On-Screen - Only selectable if all other options are not selected.
4. After adjusting all the settings, press Accept .
UNIVERSAL TERMINAL (UT) SETTINGS
The UT Settings page provides options to identify connected UT’s, clear the UT
Object Pool or change the UT instance when multiple UTs are available. To access
the UT Settings page, press UT Settings on the CRX Settings page.
LIGHTBAR CONFIGURATION
NOTE: Lightbar configuration will only be available on CR12 if a lightbar is
detected.
1. To access the Lightbar Configuration settings, press Lightbar . The
Lightbar Configuration window will open.
2. The default setting for the lightbar is that it is enabled. To disable the light-bar,
deselect the Enable checkbox.
