51
3. The default setting for the Reverse LED Indication is active. To deactivate the
Reverse LED Indication, deselect the Reverse LED Indication checkbox.
NOTE: Selecting or deselecting the Reverse LED Indication will change if the
lightbar LEDs display to the right if to the right of the guidance line or to
the left if to the right of the guidance line.
4. The default setting for Path Deviation Sensitivity is Fine. To adjust the Path
Deviation Sensitivity select the desired radial button. While adjusting the
sensitivity, note that the light bar increments along the bottom indicates the
distance off line for each light. For example, with Fine selected the first red light
will turn on when the implement is 4” (10 cm) off line, the second light will turn on
when the implement is 10” (26 cm) off line.After adjusting all the settings for the
light-bar, press Accept .
If an external lightbar is connected via the serial port, that option will display on the
Lightbar Settings page and be selected. If desired, deselect the external lightbar.
NOTIFICATIONS
Press the Notifications button to access the Notification History. To view more
information on a specific notification, press the notification. A notification window
will open displaying the notification type, additional notification details, and how
long ago the notification occurred. After reviewing the notification, press Complete
. When done viewing the notifications, press Accept .
