Raven CR7 - CRX Console Specifications; CR7 Specifications

7
SPECIFICATIONS
Connections
• 2 CANbus Channels
• 3 Serial Channels
• One USB 2.0 Port
• Gigabit Ethernet Port
• Wi-Fi 802.11 b/g/n
•Bluetooth 2.1 with EDR and BLE 4.0
• Radar Speed Output
• Keyed Power Start-Up and Shut-Down
• Two Digital Sense Inputs
Display
• Screen Brightness 850 NITS
•7” Widescreen
• Capacitive Touch
• 480 x 800 Resolution
•Integrated Lightbar
Computing
• 8 GB Storage
•2 GB RAM
• 852 MHz Quad Core Processor
Power
•7-16 VDC Input
•850 mA Typical
• Supply Power Fuse: 5 Amp MINI
®
Fuse
Mechanical
• 7.5” x 5.6” x 3.0”
• Weight: 1.4 lbs
• 1” RAM Ball Mount
Environmental
• Operating Temperature Range: -20°C to 70°C
• Storage Temperature Range: -40°C to 70°C
•IP65 Moisture Protection
• Operating Altitude: 2000m Maximum
Certifications
•CE
•E-Mark
