Raycus ABP Series User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
7
2.5 Attentions
a) Make sure that the mail power supply of AC 380V correctly connected. Wrong connection will
damage the product.
b) It is important to keep the fiber delivery cable connector clean, otherwise it will damage the product.
c) Please cap the fiber delivery cable connector when it is not in use. DO NOT touch the top lens of
the connector at any time. Use appropriate lens cleaning paper to clean it when any dust or dirt is
noticed.
d) Keep the cap safety in the storage box when using the product. To avoid dust inside the cap that may
pollute the lens of the connector, make sure the opening direction of the cap is put down.
e) Failure to follow those above instructions may cause laser power loss, such loss will not be covered
by warranty.
2.6 Specifications
Table 2 Product specifications
Optical Characteristics
Test condition
Product
1500/
1500
2000/
2000
3000/
3000
2000/
4000
4000/
2000
4000/
4000
6000/6000
Emission Power
3kW
4kW
6kW
6kW
6kW
8kW
12 kW
/
Center emission
power
1.5 kW
2 kW
3 kW
2 kW
4 kW
4 kW
6 kW
Ring emission
power
1.5 kW
2 kW
3 kW
4 kW
2 kW
4 kW
6 kW
Operation Mode
Continuous Wave / Modulated
/
Polarization
Random
/
Emission Power
Range
10%～100%
/
Emission
Wavelength
1080±5 nm
Nominal Emission
Power
Emission Power
Instability
±1.5%
Nominal Emission
Power；Continuous
running time：
greater than 5hrs；
operating
temperature ：
25℃
Modulation
Frequency
50~5000Hz
50~2000Hz
Nominal Emission
Power
Red GuideLaser
Power
0.5mW～1mW
/
Fiber delivery
cable connector
IHQB
QD
/
Center Beam
Quality *(86%)
(BPP,mm•mrad
)
＜2.2（@50um）/ ＜4（@100um）
Nominal Emission
Power
Center beam
mrad*(86%)
（mrad）
＜90(@50um) / ＜90（@100um）
Nominal Emission
Power
