Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
8.7 Raycus Laser Control Software Operating Mode Selection
The laser operating mode is set by the Raycus Laser Control Software. Its operating interface is as
Figure 53. The interpretation of the various patterns can be found in Table 15.
Figure 53 Laser operatingmode selecting
Table 15 Laser operatingmode and explanation
A concise software interface
Displays laser’s all status and parameters for diagnosis purposes
Time-limited locking function can be set on laser
Users can modify laser parameters (subject to valid password)
Figure 54 Thedisplayarea interface of the usermode selecting
