User Guide of RFL-C3000XZ~RFL-C12000XZ
28
B1
Laser ready
Output
Indicate that the laser is ready for emission.
B2
Laser emitting
Output
Indicate that the laser is emitting.
B3
Internal mode
Indicator
Output
Indicate that the laser is working in Internal mode.
B4
Abnormal
Output
Indicate that the laser is in abnormal condition.
B5
Guide laser
indicator
Output
Indicate that the laser guide laser is on.
B6
AD mode
Output
Indicate that the laser is working in AD mode.
B7
Laser receiving
request signal
Output
Indicate that the laser receives Request Signal (Pin A1).
B8
Main power on
Output
Indicate the main power is on.
B9
Waveform mode
Indicator
Output
Indicate that the laser is working in Waveform mode.
B10
Waveform mode
execution
finished
Output
Indicate that the Waveform mode is successfully done. Invalid pin
A2 will reset this pin.
B11
Waveform mode
abnormally
finished
Output
Indicate that the Waveform mode is abnormally finished. Reset (Pin
A4) will reset this pin.
B12
Synchronization
signal output
Output
High level valid, low level invalid
B13
Alarm
Output
Indicate that the laser is having alarms.
B14
Backup
/
/
B15
External power
source +
/
External power source of 24V. All output pins are effective when
Pin B15 and B16 are connected with 24V external power source.
B16
External power
source -
/
D1~D4
Working optical
gate indicator
Output
Indicating the current working Optical Gate:
0000- Optical Gate disabled
0001-Optical Gate 1 is working
0010-Optical Gate 2 is working
0011-Optical Gate 3 is working
D1 low level，D4 high level
(Only working for laser source featuring Optical Gate, and as
standby for normal models)
D5
Cooler warning
Output
Warning for the current cooling water temperature.
D6
Cooler alarm
Output
Alarm for the current cooling water temperature.
D7
QCW mode
Output
Indicate the laser source is working in QCW mode
(Only for model featuring QCW function)
D8~D11
Hardware
address
Output
Coding-Cable function
0000- Laser source number 0
0001- Laser source number 1
D8 low level，D11 high level
D12~D16
Backup
/
/
