Digitalradarcableextension
IfrequiredyoucanuseaRaymarinedigitalradarextensioncable.
D11 68 7-1
1
2
1.Extensioncable
2.Digitalscannercable
Note:Theextensioncableconnectstotheradarscanner.
Digitalradarcables
Youwillneedatleast2cablestoconnectthedigitalradarscanner.
OnecableconnectsthescannertoaSeaT alk
hs
switch(orcrossover
coupler).Thesecondcablethenconnectsintothedisplay.
Note:Themaximumcablelengthincludingallextensionsis25m
(82ft).
