Raymarine E90W Installation Instructions

Sonarconnection
Thesonarconnectionisrequiredforshnderapplications.The
displayisconnectedtoasonarmodule(DSM)usingaSeaT alk
hs
cable.Youwillalsorequireacompatibletransducerconnectedto
theDSMunit.
D116 80 -1
SeaTalk
hs
SeaTalk
hs
1
2
3
1.Display
2.SeaTalk
hs
switch
3.DSMunit,e.g.DSM400
TheE-SeriesWidescreendisplaycanbeusedwiththefollowing
DSMunits:
•DSM400
•DSM300
•DSM30
Thedisplaycansupport1DSMmodule.
Sonarconnecteddirectlytothedisplay
Onsmallersystems(withonlyonedisplayandnootherdigital
devices)theDSMmaybeconnecteddirectlytothedisplaywithout
usingaSeaT alk
hs
switch.
Note:Youmustensurethatthecableendsconnectedintothe
displayandDSMhavealocking/weathertightmechanism.
TypicalDSMsystem
D11 68 1-1
SeaTalk
hs
1 2
3
4
