2.6Optionaladditionalcomponents
Thefollowingoptionalproductsanddevicescanbeusedwithorconnectedtoyourdisplay.
•MicroSD
memory/electroniccartographycard—Insertingacompatiblememorycardintothe
cardreaderenables:
–displayofcompatibleelectroniccartography.
–collectionanddisplayofRealbathy™personalsonardata.
–Backupandrestoreofuserdataandsettings.
–savingscreenshotimagefiles.
•EV-1Headingsensor(E70096)—ConnectingthedisplaytoaNMEA2000/SeaTalkng®backbone
thatincludesanEV-1enablesvesselheadingdatatobeavailable,regardlessofvesselmovement.
•ECI-100(E70227)—ConnectingthedisplaytoaNMEA2000/Sea Talkng®backbonethatincludes
anECI-100enablesdisplayofcompatibleenginedata.Forfurtherinformationoncompatible
enginesreferto:Compatibleenginesystems
,page21
•Third-partytanklevelsensors—ConnectingthedisplaytoaNMEA2000orSeaTalkng®backbone
thatincludesstandardthird-partyNMEA2000tanklevelsensorsenablesthedisplayoftanklevel
sensordata.Forfurtherdetailsontanklevelsensorsreferto:Compatibletanklevelsensors
,page22
•VHFradio—ConnectingthedisplaytoaNMEA2000orSeaTalkng®backbonecanprovide
positiondatatoacompatibleVHFradio.
•RS150GNSSreceiver(E70310)—ConnectinganexternalGNSS/GPSreceivercanprovidemore
accuratepositiontracking.
•AIS700/AIS650/AIS350(E70476/E32158/E32157)—ConnectingcompatibleAIShardware
allowsAIStargetstobetrackedinthechartapp.
•iTC-5(E70010)—ConnectingthedisplaytoaNMEA2000/SeaTalkng®backbonethatincludes
analogtransducersconnectedviaaniTC-5enablesthedisplayoftransducersensordata(depth,
speed,wind,watertemperatureetc.))indataboxesandthedashboardapp.RefertotheiTC-5
installationinstructions(87138)forfurtherinformationonconnectinganalogtransducersviaan
iTC-5.
Note:Transducer calibrationisnotsupportedbythedisplayandmustbeperformedonan
appropriateSeaTalkng®instrumentdisplaysuchasthei70Smultifunctioninstrumentdisplay.
•Airmar NMEA2000smartsensors—ConnectinganAirmarsmartsensorsuchasaDST800
orP79.
Datacompatibility
Inadditiontoproductslistedascompatibleinthisdocument,yourproductcanalsoreceiveand
displaydatafromotherNMEA2000devices.
FordatatobedisplayedonscreenthedisplaymustreceivedatafromNMEA2000devicesusing
supportedNMEA200PGNmessages.
AlistofNMEA2000PGNmessagesthataresupportedbyyourdisplaycanbefoundintheappendix
ofthisdocument:SeaTalkng®cablesandaccessories,page82
Compatibleenginesystems
WhenconnectedtoanNMEA2000/SeaTalkng®backboneviaanECI-100enginegateway(E70227),
enginedataforuptotwocompatibleenginescanbedisplayed.Thefollowingenginesystems
aresupported.
•VolvoPentaElectronicVesselControl(EVC)systems
•Y amahaMarineCommandLink
•Y amahaMarineCommandLinkPlus
•Y anmarenginesystems
•Hondaengines
•Caterpillarenginesystems(mustincludeMPD,MPDcolororminiMPD)
Documentandproductinformation
