8.1
Elementtechnicalspecification
Power
Element™7Element™9Element™12
Nominalsupply
voltage:
12Vdc
Operatingvoltage
range:
8Vdcto16Vdc(protectedupto32Vdc)
Fuserequirements:
•Inlinefuse=5Amp,
or
•Thermalbreaker=3Amp
NMEA2000LEN(Load
Equivalency Number):
1
Environmental
Element™7Element™9Element™12
Operatingtemperature
range:
-25°C(-13°F)to+55°C(+131°F)
Storage temperature
range:
-30°C(-22°F)to+70°C(+158°F)
Humidity:
upto93%@40°C(+104°F)
Water ingress
protection:
IPx6andIPx7
Weight (displayonly):
1.0Kg1.3Kg2.0Kg
LCD specification
Element™7Element™9Element™12
Size(diagonal):
7.0”9 .0”12.1”
Type
TN (TwistedNematic)IPS(In-PlaneSwitching)
Colordepth:24bit
Resolution:
WV GA800x480WXGA1280x800
Ratio
5:38:5
MaximumIllumination:
1500nits/1500cd/m
2
Viewingangle(T/B/
L/R):
50°/60°/70°/70°50°/70°/70°/70°89°/89°/89°/89°
Dataconnections
Element™7Element™9Element™12
Transducer:1 x15–pinHyperVision™connector.
SeaT alkng®/NMEA
2000
1xDeviceNetfemaleconnectorbuiltintopowercable
2.4GHzWi-Fi:
1x802.11/b/g/n
Storage
Element™7Element™9Element™12
External:
1xMicroSDX Ccardslot
