Raymarine Element - HV-100 Transducer Extension Cable; HV-300 Transducer Extension Cable

HV-300THP-PandHV-300THP-S(splitpair)connection
1.Extensioncable(suppliedwithsplitpairsetsoftransducers).
2.Y-cable(suppliedwithsplitpairsetsoftransducers).
Y
ou canextendthelengthoftransducercablesusingatransducerextensioncable.
HV–100transducerextensioncable
Forbestperformance,cablerunsshouldbekepttoaminimum.However,forsomeinstallationsit
maybenecessarytoextendthetransducercable.
A4m(13.12ft)HyperVision™transducerextensioncable(A80562)isavailable
Itisrecommendedthatamaximumofonecableextensionsisused,withthetotalcablelength
notexceeding10m(32.81ft).
Note:
TheHyperVision ™transducerextensioncablecanonlybeusedtoconnectaHVseriestransducer.
HV–300 transducerextensioncable
Forbestperformance,cablerunsshouldbekepttoaminimum.However,forsomeinstallationsit
maybenecessarytoextendthetransducercable.
A4m(13.12ft)HyperVision™transducerextensioncable(A80562)isavailable
Itisrecommendedthatamaximumofonecableextensionsisused,withthetotalcablerunto
eachtransducernotexceeding6.3m(20.67ft).
Note:
TheHyperVision ™transducerextensioncablecanonlybeusedtoconnectaHVseriestransducer.
