4.3Power
connection
Thepowercablemustbeconnectedtoa12Vdcpowersupply,thiscanbeachievedbyconnecting
directlytoabattery,orviathedistributionpanel.Theproductisprotectedagainstreversepolarity.
1.Power/NMEA 2000cableconnectstotherearofthedisplay.
2.GroundwireconnectstoRFgroundpoint,ifnogroundpointisavailableconnecttothebattery
negative(-)terminal.
3.Positive(Red)wireconnectstobatterypositive(+)terminal.
4.Waterprooffuseholderwith5Ainlinefusemustbefitted(notsupplied).
5.Negativewireconnectstobatterynegative(-)terminal.
Important:
To preventerraticbehaviorandpotentialdataloss,ensuretheproductissuppliedfromaseparate
batteryfromthatusedforenginestart.
In-linefuseandthermalbreaker ratings
Thefollowingin-linefuseandthermalbreakerratingsapplytoyourproduct:
In-linefuse
ratingThermalbreaker rating
5A
3A
Note:
•Thesuitablefuseratingforthethermalbreaker isdependentonthenumberofdevicesyouare
connecting.IfindoubtconsultanauthorizedRaymarinedealer.
•Y ourproduct’spowercablemayhaveanin-linefusefitted,ifnotthenyoumustaddanin-line
fuse/breakertothepositivewireofyourproduct’spowerconnection.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethepowersourceisadequatelyprotectedby
meansofasuitably-ratedfuseorautomaticcircuitbreaker.
