8.2HyperVision
™technicalspecification
ThefollowingspecificationonlyappliestoHyperVision™products.
Power
•
1.2MHz(Hyper)=1000W
•350kHz(Standard)=700W
•200kHz(ConicalhighCHIRPsonar)=100W
Frequencies
•1.2MHzCHIRP
•350kHzCHIRP
•200kHzCHIRP
Channels•ConicalhighCHIRPsonar
•RealVision ™3D(Hyper)
•RealVision™3D(Standard)
•SideVision™(Hyper)
•SideVision™(Standard)
•DownVision™(Hyper)
•DownVision™(Standard)
200kHzrange
•ConicalhighCHIRPsonar=0.6 M(2ft)to274m(900ft)
350kHz(Standard) range•RealVision™3D=0.6M(2ft)to91m(300ft)
•SideVision™=0.6M(2ft)to91m(300ft)eachside
•DownVision™=0.6M(2ft)to183m(600ft)
1.2MHz(Hyper)range•RealVision ™3D=0.6M(2ft)to38m(125ft)
•SideVision™=0.6M(2ft)to38m(125ft)eachside
•DownVision™=0.6M(2ft)to38m(125ft)
Technical specification
