Raymarine Element - Cable Routing

Caution:Transducer
cable
•DoNO
T
usethetransducercabletoliftorsuspendthetransducer;always
supportthetransducerbodydirectlyduringinstallation.
•DoNOTcut,shorten,orsplicethetransducercable.
•DoNOTremovetheconnector.
Ifthecableiscut,itcannotberepaired.Cuttingthecablewillalsovoidthe
warranty.
Cablerouting
Cableroutingrequirementsforthetransducercable.
Important:
To avoidinterference,thecablemustberoutedasfarawayfromVHFradioantennadevices
andcablesaspossible.
•Checkthatthecableislongenoughtoreachthedisplayitwillbeconnectedto. Optionalextension
cablesareavailable,ifrequired.
•Ensurethereisenoughslackinthetransducercable,atthetransducerend,toallowthetransducer
topivotupanddownduringadjustment.
•Ifyouintendtoroutethecablethroughthetransomthenyoushouldusethesuppliedescutcheon
platetocoverthehole..
•Securethecableatregularintervalsusingthesuppliedcableclips.
•Anyexcesscableshouldbecoiledupataconvenientlocation.
Connections45
