Raymarine Element - Element HV Legacy Transducer Connection; Legacy Transducer Extension Cables

4.5Element™HVlegacytransducerconnection
Whenconnectingalegacytransduceryoumustusethecorrectadaptorcableand,whererequired
anextension
cablethatiscompatiblewiththelegacytransducer.
1.Element™HVdisplay—Connectstoadaptorcable..
2. Adaptorcable(i.e.:A80559orA80558)—Connectstothedisplayandextensioncableor
transducer.
3.Extensioncable(i.e.:A80312,E66074orA80273)—Connectsbetweentransducerandadaptor
cable.
4.Examplelegacytransducer—Connectstoadaptorcableorextensioncable.
Legacytransducerextensioncables
WhenconnectingacompatiblelegacytransducertoanElementdisplay,usinganadaptorcable:
ifthecablerunrequiresextending,youmustuseanextensioncablewhichiscompatiblewith
yourtransducer.
Important:
TheHyperVision ™extensioncablecannotbeusedtoextendthecablerunoflegacytransducers.
Legacy transducerCompatibleextensioncable
Dragonfly®transducers
A80312 —4m(13.1ft)Dragonfly®transducer
extensioncable.
Note:
Powersupplywiresshouldbeisolatedand
protectedfromshortingorwateringress.
DownVision ™transducers
E66074—3m(9.84ft)DownVision™transducer
extensioncable.
HighCHIRPsonartransducers
A80273 —4m(13.1ft)CPT-Stransducer
extensioncable.
