3.
1Productoverview
TheRVM-4xxseriestransducersareRealVisionMax3Dstainlesssteel
thru-hulltransducers.
InconjunctionwithaRealVisionMax3Dcompatiblemultifunctiondisplay
orsonarmodule,theRVM-4xxseriestransducersproducerealistic3D
representationsoftheobjectsbelowyourvessel,tohelpyouidentify
underwaterstructuresandlocatefish.
RealVisionMax3Dtransducersbenefitfromimprovedpingratesandtighter
beamwidths,resultinginsharpersonarimages,detailedwrecks,anddistinct
fishtargets.RealVision™Max3Dtransducersalsoprovidehighercontrast
colorpalettesforaccentuatingtargets,allowingfishtargetstostandout
fromthewatercolumnnoise.
Sonarchannels:
RealVisionMax3Dtransducersofferthefollowingsonarchannels:
RealVision™Max3D
SideVision
DownVision
ConicalHighCHIRP/LowCHIRP600W/200kHz
RealVisionMax3Dtransducersincludeabuilt-inAHRS(Attitudeand
HeadingReferenceSystem)sensorthathelpsstabilize3Dimaging
automatically,bycompensatingforvesselmotion.
Stainlesssteeltransducersaresuitableforinstallationsonvesselswith
fiberglass,metalorwoodenhulls.
Important:
Wheninstallingthetransduceronavesselthathasametalhullyou
mustuseALLofthesuppliedisolatorpartstoensurethetransducer
metalworkisfullyisolatedfromthemetalhull.
DoNO Tinstallstainlesssteeltransducersonvesselswithapositive
groundsystem.
Thesetransducersarecapableofproducing3Dsonarimageswhen
connectedtoaR ealVisionMax3DvariantMFDrunningLightHouse™4
software,oraLightHouse™4compatibleMFDusedinconjunctionwithan
RVM1600RealVision™Max3Dsonarmodule.TheRVM-4xxseriesincludes
5transducervariants,eachhavingthesameexternalshapeanddimensions.
Thetransducersdifferinternally,andcontaindifferentnumbersandtypes
oftransmitandreceiveelements.Y ourinstallationshouldcompriseeither
asingleRVM-400transducer,orasplit-pairofRVM-412sorRVM-420s
transducers.
Thehullgeometryofyourvesseldeterminesthemostappropriate
transducerstouse.Y oushouldfittransducerswhoseelementsareangledto
matchwithin±6°ofyourhull’sdeadriseangle,asdetailedbelow:
RVM-400RealVisionMax3Dstainlesssteel(fordeadriseto6°)
thru-hullall-in-onetransducer(Partnumber:A80704)
RVM-412PortandRVM-412StarboardRealVisionMax3Dstainlesssteel
12°(fordeadriseto18°)thru-hullsplit-pairtransducers(Systempack
partnumber:T70543)
RVM-412Portporttransducer(Partnumber:A80705)
RVM-412Starboardstarboardtransducer(Partnumber:A80706)
RVM-420PortandRVM-420StarboardRealVisionMax3Dstainless
steel20°(fordeadrise14°to26°)thru-hullsplit-pairtransducer(System
packpartnumber:T70544)
RVM-420Portporttransducer(Partnumber:A80707)
RVM-420Starboardstarboardtransducer(Partnumber:A80708)
Productandsystemoverview
13
